| Ref |
Class |
Part |
Description |
Qty |
Comment |
| 1 |
3303 |
8231752 |
CARBURETOR
ASSEMBLY |
1 |
(3) |
| 1 |
3303 |
8230402 |
CARBURETOR
ASSEMBLY |
1 |
(2.5)
SN# USA-0G574241/BEL9973099 & Below |
| 1 |
3303 |
823040A
2 |
CARBURETOR |
1 |
(2.5)
SN# USA-0G574242/BEL9973100 & Up |
| 2 |
|
95252 |
WIRE,
Throttle |
1 |
|
| 3 |
10 |
95321 |
BOLT |
1 |
|
| 4 |
|
95253 |
BRACKET |
1 |
|
| 5 |
|
95254 |
CAP |
1 |
|
| 6 |
24 |
95322 |
SPRING |
1 |
|
| 7 |
|
95255 |
PLATE |
1 |
|
| 8 |
53 |
95323 |
E
RING |
1 |
|
| 9 |
|
815126A
1 |
JET
NEEDLE |
1 |
(SEE
NOTE 1) |
| 9 |
|
823041 |
JET
NEEDLE |
1 |
(2.5)
(SEE NOTE 2) |
| 9 |
|
8151262 |
JET
NEEDLE |
1 |
(2.5)
SN# USA-0G574242/BEL9973100 & Up |
| 9 |
|
8151261 |
JET
NEEDLE |
1 |
(3) |
| 10 |
|
95257 |
VALVE,
Throttle |
1 |
SN#
USA-0G574241/BEL9973099 & Below |
| 10 |
|
952573 |
VALVE,
Throttle |
1 |
SN#
USA-0G574242/BEL9973100 & Up |
| 11 |
|
815126A
1 |
JET
NEEDLE |
1 |
|
| 12 |
27 |
95324 |
GASKET |
1 |
|
| 13 |
|
95259 |
FLOAT |
1 |
|
| 14 |
|
95260 |
FLOAT
BOWL |
1 |
|
| 15 |
17 |
95327 |
PIN,
Hinge |
1 |
|
| 16 |
|
95263A
1 |
HINGE |
1 |
|
| 16 |
|
952621 |
HINGE |
1 |
|
| 17 |
|
815029 |
MAIN
JET (#92) |
1 |
SN#
USA-0G574241/BEL9973099 & Below |
| 17 |
|
8150291 |
MAIN
JET (#80) |
1 |
SN#
USA-0G574242/BEL9973100 & Up |
| 18 |
10 |
95325 |
SCREW |
1 |
|
| 19 |
27 |
95326 |
GASKET |
1 |
|
| 19 |
27 |
953261 |
GASKET |
1 |
|
| 20 |
|
95263 |
VALVE,
Needle |
1 |
|
| 20 |
|
95263A
1 |
HINGE |
1 |
|
| 21 |
|
95264 |
SEAT |
1 |
|
| 21 |
|
952641 |
SEAT,
Needle Valve |
1 |
|
| 22 |
10 |
95328 |
SCREW |
1 |
|
| 23 |
24 |
95329 |
SPRING |
1 |
|
| 24 |
|
95266 |
LEVER,
Shutter |
1 |
|
| 25 |
10 |
95331 |
SCREW |
1 |
|
| 26 |
|
95265 |
PLATE,
Choke |
1 |
|
| 27 |
13 |
400256 |
LOCKWASHER,
(M6) |
1 |
|
| 28 |
11 |
95330 |
NUT |
1 |
|
| 29 |
54 |
95332 |
CLAMP |
1 |
|
| 30 |
10 |
95333 |
SCREW |
1 |
|
| 31 |
25 |
811601 |
O-RING |
1 |
|
| 32 |
10 |
815071 |
SCREW |
2 |
|
| 33 |
|
95268 |
LEVER,
Throttle |
1 |
|
| 34 |
10 |
815072 |
SCREW |
1 |
|
| 35 |
13 |
95238 |
LOCKWASHER |
1 |
|
| 36 |
27 |
95336 |
GASKET |
2 |
|
| 37 |
|
95267 |
BRACKET |
1 |
(SEE
NOTE 1) |
| 37 |
|
952672 |
BRACKET |
1 |
|
| 38 |
23 |
95286 |
COLLAR |
1 |
SN#
USA-0G574241/BEL9973099 & Below |
| 38 |
23 |
952867 |
COLLAR |
1 |
SN#
USA-0G574242/BEL9973100 & Up |
| 39 |
|
95269 |
KNOB |
2 |
|
| 40 |
10 |
95338 |
SCREW |
2 |
|
| 41 |
|
815073 |
COVER |
1 |
(BLACK) |
| 41 |
|
815132 |
COVER |
1 |
(MARINER
GRAY) SN# USA0G574241/BEL-9973099 & Below |
| 41 |
|
8151321 |
COVER |
1 |
(FORCE
GRAY) |
| 42 |
|
8150731 |
COVER |
1 |
(BLACK)
SN# USA0G574242/BEL-9973100 & Up |
| 42 |
|
8150732 |
COVER |
1 |
(MARINER
GRAY) SN# USA0G574242/BEL-9973100 & Up |
| 43 |
10 |
95339 |
SCREW |
1 |
|
| - |
|
855546A
2 |
REPAIR
KIT, Carburetor |
1 |
(2.5) |
| - |
27 |
815076A
1 |
GASKET
SET, Powerhead |
1 |
|
|
|
|
